Main feature：

1.  Material tank：

1) Equipped with 2 1000L material tanks, the inner liner is of stainless steel jacket type, the power of the stirring motor is 11KW, which is used for premixing the resin material.

2) Equipped with a 300L material tank, the inner liner is stainless steel jacket type, used for curing agent.

2. Pump set：

1) One metering pump: gear pump, stepless speed regulation, power 5.5KW, explosion-proof motor.

2) One curing agent metering pump, equipped with a hydraulic diaphragm metering pump, power 0.37KW, explosion-proof motor.

3) A cyclopentane feeding pump: equipped with a hydraulic diaphragm metering pump, power 0.37KW, explosion-proof motor.

4) One phenolic resin feeding pump: equipped with a rotor pump, power 3KW, explosion-proof motor.

3. Mixing head set：

1) A set of mechanical mixing head, mixing speed 4500rpm/min, power 2.2KW explosion-proof motor.

2) Equipped with automatic cleaning device (including a 25L cleaning tank, made of stainless steel).

4. Raw material temperature control system：

Equipped with a 5-hp chiller and corresponding water-liquid electric valve, the real number of material temperature is displayed and adjustable, equipped with a heating water tank, and the power is 6KW. The system can realize automatic control of the raw material temperature.

5. Combustible gas monitoring system：

The combustible gas on the foaming system is detected, equipped with 6 combustible gas control and measuring instruments, which can automatically alarm and activate the exhaust system at the same time to effectively discharge the flammable and explosive gas in time.

Equipped with 2 fans, 6 sets of combustible gas detectors and a set of monitors, with corresponding ventilation ducts.
Fan power 4KW 20000m3/h wind pressure 0.3MPa.

6. Electric control cabinet：

The foaming machine adopts PLC control, and the casting calibration time, cleaning time, blowing time and action program can be preset.

Company and service advantages:

1.The company workshop 40,000 square meters, has introduced the first-class multi-station machining center, CNC lathes, CNC milling machines and other high-precision processing equipment. Such as the value of 4.5 million yuan 3mx8m gantry machining center, and the value of 300 million yuan 2.5 mx12m gantry milling machine.

2.The company has a professional The Adjuster team, 24 hours to provide uninterrupted after-sales service.
(1) Installation and debugging
Equipment arrived at the customer workshop, according to the flat layout of our equipment. We will arrange experienced technicians to install, debug and test-produce the equipment, and make the equipment reach the rated production capacity of the production line.
(2) Training
Our company provides technical training for our customers. The training includes the structure and maintenance of the equipment, the control and operation of the equipment, experienced technicians will guide and establish the training program. After training, the buyer's technical personnel can master the operation and maintenance of the equipment, can adjust the process and deal with different failures.

3.After-sales quality problems within 2 hours to answer, if the telephone video guidance can not be solved, domestic 24 hours to send engineers to the site to solve the problem.

4. Factory direct sales price concessions, 40,000 square meters factory, 20 years of Export Enterprises, CE certification, patents more than 50 items.
